A 4020 24V Part Cooling Fan is a compact blower fan commonly used in 3D printers to provide targeted cooling to the printed material, enhancing print quality and detail. The "4020" designation refers to the fan's dimensions: 40mm in length and width, and 20mm in thickness.
Features:
-
Efficient Cooling: Delivers focused airflow to rapidly solidify extruded filament, reducing defects such as stringing or sagging.
-
Durable Bearings: Dual ball bearings offer longer lifespan and can operate continuously, while hydraulic bearings provide a balance between performance and noise levels.
-
Low Noise Operation: Designed to maintain effective cooling with minimal acoustic disturbance.
Installation Considerations:
-
Mounting: Verify that the fan's dimensions align with your printer's mounting points to facilitate secure installation.
-
Wiring: Pay attention to wire length and connector type to ensure seamless integration without the need for modifications.
Technical specifications
Key Specifications:
-
Dimensions: 40mm x 40mm x 20mm
-
Operating Voltage: 24V DC
-
Current Draw: Typically around 0.1A
-
Airflow: Approximately 3.67 to 6.68 CFM, depending on the model
-
Noise Level: Ranging from 23 to 36 dBA
-
Bearing Types: Options include dual ball bearings, hydraulic bearings, and sleeve bearings
-
Connector Type: Commonly equipped with a 2-pin JST plug
Will it work with my printer?
Reviews
What our customers are saying
No reviews yet — be the first to leave one.
Part Cooling Fan 4020 24V
All orders are shipped from Canada. Duties, taxes, and tariffs may apply.
